Compression Heat Dryer

Overview

Yipu Compressed Heat Dryer achieves three core breakthroughs through innovative compressed heat utilization technology:

1. Zero Additional Energy Consumption: Fully utilizes waste heat from air compressors, requiring no external energy for regeneration—reducing annual operating costs by over 60% compared to traditional equipment.
2. Deep and Stable Drying: Delivers a pressure dew point of -70℃, meeting the most stringent process requirements with dew point stability far exceeding conventional dryers.
3. Rapid Investment Payback: Typically recovers equipment investment within 1-2 years, offering significant long-term operational benefits.

This product is particularly suitable for large air compressor stations with annual operating hours exceeding 6,000 hours, serving as the preferred solution for deep energy-saving upgrades of compressed air systems.

I. Market Pain Point Analysis

1. Massive Energy Consumption of Traditional Dryers
   • Heated regenerative dryers require additional electrical energy for heating, resulting in high electricity costs.
   • Heatless regenerative dryers consume 15-20% of finished compressed air, causing severe waste.
2. Low Comprehensive Energy Utilization Efficiency
   • High-temperature exhaust air (110-150℃) from air compressors is directly discharged, leading to significant energy waste.
   • Enterprises face persistently high energy costs and large carbon emissions.
3. Unreliable Dew Point Stability
   • Conventional dryers exhibit unstable dew points when load fluctuates.
   • This compromises the quality of high-end manufacturing and precision processes.

II. System Process Flow

Compressed Heat Utilization System:

1. Direct Utilization of High-Temperature Compressed Air
   • High-temperature air (110-150℃) discharged from the air compressor directly enters Adsorption Tower A.
   • The adsorbent maintains excellent adsorption performance under high-temperature conditions.
2. Synchronous Adsorption and Regeneration
   • While Tower A performs adsorption and produces dry air, Tower B uses waste heat from the system for regeneration.
   • Regenerated gas is discharged after cooling and separation.
3. Intelligent Switching Control
   • PLC controls automatic switching with an 8-hour standard cycle.
   • Optional dew point meter control enables on-demand regeneration.
4. Waste Heat Recovery System
   • Built-in high-efficiency heat exchanger fully utilizes compressed heat.
   • Optional auxiliary electric heating for extreme working conditions.

III. Working Principle

Temperature Swing Adsorption (TSA) Mechanism:

• Utilizes the adsorbent’s varying adsorption capacity at different temperatures.
• Adsorption capacity decreases at high temperatures, enabling deep regeneration.
• Adsorption capacity increases at low temperatures, ensuring deep drying.

Direct Compressed Heat Utilization:

• Exhaust heat from the air compressor is directly used for regeneration, requiring zero additional energy.
• Regeneration air consumption ≤6%, far lower than traditional equipment.

IV. Core Competitive Advantages

1. Ultimate Energy-Saving Effect
   • Zero external energy consumption for regeneration.
   • 100% more energy-efficient than heated regenerative dryers and over 50% more efficient than heatless regenerative dryers.
2. Stable Deep Drying
   • Pressure dew point stably maintained at -40℃ to -70℃.
   • Combined adsorption bed design ensures high-temperature adsorption capacity.
3. Intelligent Control System
   • PLC programmable control with remote monitoring support.
   • Multiple safety protections for reliable operation.
4. Long-Life Design
   • Unique air distribution device prevents adsorbent pulverization.
   • High-quality valves with a switching service life of up to 1 million cycles.

V. Technical Strength

Innovative Technologies:

• High-temperature adsorbent formulation technology.
• Efficient compressed heat utilization technology.
• Intelligent heat management system.

Manufacturing Processes:

• Integrated skid-mounted design ensures installation precision.
• Strict airtightness testing standards.
• Professional adsorbent filling process.

VI. Product Series Introduction

Standard Series:

• YR-100 Series: 85.5-120 Nm³/min
• YR-200 Series: 150-250 Nm³/min
• YR-300 Series: 300-400 Nm³/min
• YR-500 Series: 450-510 Nm³/min

Customization Options:

• Auxiliary electric heating system.
• Online dew point monitoring system.
• Remote monitoring interface.

VII. Application Scenario Solutions

Energy-Intensive Industries:

• Centralized air supply for large air compressor stations.
• Iron and steel metallurgical enterprises.
• Chemical production bases.

High-End Manufacturing:

• Automotive manufacturing spraying workshops.
• Electronic semiconductor factories.
• Precision instrument manufacturing.

Continuous Production Processes:

• Chemical fiber production enterprises.
• Food and beverage processing.
• Pharmaceutical industry.

VIII. Detailed Technical Specifications

Parameter Category	Technical Indicators	Remarks
Operating Conditions
Inlet Air Temperature	≥110℃~150℃	Utilizes high-temperature exhaust from air compressor
Working Pressure	0.6-1.0 MPa	Standard: 0.7 MPa
Inlet Oil Content	≤0.1 PPM	Pre-installed precision filter required
Performance Indicators
Pressure Dew Point	≤-40℃~-70℃	Deep drying
Regeneration Air Consumption	≤6%	Extremely low air consumption
Pressure Loss	≤0.04 MPa	Low-resistance design
Air Processing Capacity	85.5-510 Nm³/min	Large-scale equipment series
Technical Configuration
Adsorbent	High-strength specialized adsorbent	High-temperature resistance
Working Cycle	8-hour standard or dew point control	Intelligent optional
Control Mode	PLC programmable control	Fully automatic operation
Installation Method	Indoor flat ground, no foundation required	Rapid deployment
Utility Requirements
Cooling Water Pressure	0.2~0.4 MPa	Industrial circulating water
Cooling Water Temperature	≤32℃
Power Supply	220V/50HZ
Power Consumption	100W	Control system only
Water Consumption	32-200 T/h	Determined by processing capacity
Structural Parameters
Equipment Weight	4100~18500 kg	Heavy-duty equipment
Overall Dimensions (L×W×H)	L(3050~8000)×W(2100~3300)×H(2200~2850) mm	Integrated skid-mounted design
